Let there be light (again)

There was a broken light switch in the upstairs hall.  Since I knew I was going to go through the trouble of replacing the switch, I decided to get another fancy smart switch.  This time I went with the TP-Link Smart Wi-Fi Light Switch.

The TP-Link switch is a lot like the WeMo switch (see part 2).  In fact, it was an accident that I got that switch–I intended to get another WeMo, but wasn’t paying attention and bought the TP-Link instead.  It took awhile for me to notice that things were different.

The wiring of the switch was simple and pretty much identical to what I did for the WeMo.  I did notice that the switch packaging was different, and the switch was slightly different, but the differences are so minor that I initially assumed I had a slightly different model of the same thing.

It wasn’t until I started trying to connect the TP-Link switch to the Echo that I ran into problems.  Most of the problems stemmed from the fact that I was going through the same steps I did for the WeMo.  Once I realized that the switch was different, it wasn’t immediately obvious where to find instructions (there was nothing helpful in the box).  After searching online, I discovered that the setup is a bit more complicated and required installing the TP-Link Kasa app, creating a Kasa account, installing a special Alexa skill, and linking the accounts.

Now that everything is set up and working, there’s no different from the WeMo in terms of functionality.  The switch works like a switch and the lights can also be voice activated via Alexa.  The thing that I like least about the switch was that the setup was comparably more complicated, but some of that was due to incorrect assumptions on my part.

Configuring a Raspberry Pi from Another Computer

Introduction

One thing I like about the Raspberry Pi is that it’s a small gadget that, once configured, only needs power in order to sit somewhere and do something.  For example, BakBoard runs on a Raspberry Pi that only plugs into a TV (for both power and display).  Unfortunately, in order to get everything running, I typically have ended up connecting various extra wires (network, keyboard, mouse, display) and work directly on the Pi before I can stick it in some random location to do what I want it to do.  Below are the steps I figured out so that I can do everything from my main computer and the only wire I need to my Pi is for power.

Prereqs

  • My main computer is currently running Ubuntu 16.04 although I think it would be easy to adapt the steps for most operating systems.
  • I have an SD card (32 GB in my case, but it probably only needs to be about 4GB).
  • I have an SD card adapter so I can read/write the SD card from my computer.

OS Image

To get the base image, I went to the Raspberry Pi Downloads Page and grabbed the latest Raspbian image (specifically 2017-01-11-raspbian-jessie-lite).  Once I had downloaded the zip, I opened it and then doubled clicked the image file (2017-01-11-raspbian-jessie-lite.img).  This brought up the Ubuntu image tool and it was easy to “restore” the image to the SD Card.

Wireless Networking

Since I don’t want to mess with a network cable, I want my Pi to be able to access my wireless network.  In order to do so, I modified the interfaces file.  It is in the image at etc/network/images.  Basically I changed the bit:

iface wlan0 inet manual
    wpa-conf /etc/wpa_supplicant/wpa_supplicant.conf

To be:

iface wlan0 inet dhcp
    wpa-ssid "NATHANS_NETWORK"
    wpa-psk "NATHANS_PASSWORD"

Obviously I plugged in the correct network name and password.

Enable SSH

The Raspbian OS used to have SSH enabled by default, but last year that changed as a security precaution.  The explanation for the change (and where I learned to do what is described below) is described on the Raspberry Pi Blog.

Basically, to enable ssh, I just create a file called “ssh” in the boot directory.  The contents of boot/ssh don’t matter–apparently the OS will see that file, enable ssh, and then delete the file.  The tricky part was that there were two “boot” directories.  There was one at the root of the volume, but there was actually a separate volume as well that is named boot–that’s the one where the ssh file must be created.

Authentication

The default password to  the Raspberry Pi is well-known which is nice because I don’t have to remember yet another password, but also a security risk since everyone knows it.  Instead, I like to use key based authentication and disable password authentication for ssh access.  Here’s how I did that:

First, I generated my public and private key (that was done a long time ago, and there are plenty of sources on the Internet how to do that).  My public key is id_rsa.pub (in the .ssh folder in my home directory) and the private key is id_rsa.  That creation was on my main computer.  Then, on the Raspberry Pi volume, I created the directory home/pi/.ssh.  I then copied the public key file (id_rsa.pub) into the home/pi/.ssh folder and also copied the file and named the copy “authorized_keys”.

Then, to disable password authentication via SSH I opened up the file etc/ssh/sshd_config in a text editor and changed:

#PasswordAuthentication yes

UsePAM yes

To be:

PasswordAuthentication no

UsePAM no

Conclusion

Once the above has been completed, I can stick the SD card into the Raspberry Pi and then plug in the Pi (giving it power).  It automatically connects to the wifi and I’m able to SSH into it without a password.  There’s nothing new here that can’t be found in various places online, but I’ve gathered the pieces together for my own reference at least.  Here are a few “gotchas” I encountered along the way:

  • All of the paths mentioned above are relative paths–the volume might be mounted in various places–in my place it was something like /media/nathan/90asd8f60s9g69789sd6gjherlkuyds8 for the main volume and /media/nathan/boot for the boot volume.
  • As mentioned before, there are two “boot” directories–make sure that the “ssh” file is created in the boot volume.
  • In order to create/modify some of the files, I had to use sudo (or change to root).
  • I the past, I used to have to run raspi-config to expand the volume to use all available space on the SD card, but that no longer seems necessary–it now seems to happen automagically.
  • Even though password authentication is disabled for SSH access, whenever logging in there is still a warning.  I usually do change the password and just write it down somewhere since I never use it.

And the question is?

I was still in elementary school when I was first introduced to The Hitchhiker’s Guide to the Galaxy.  Initial contact was the 1984 video game on a Commodore 64 which I initially thought to be a clone of Zork, but quickly discovered it was much sillier.  I died frequently and never made it very far, but I learned to put on a robe before trying to access the pockets and to lay down in front of bulldozers.

Later (but still during my elementary school years), the BBC showed the television series.  I was expecting something like Doctor Who (and Douglas Adams even wrote “City of Death” which is one of my favourite Doctor Episodes), but quickly discovered it was much sillier.  Of all the bits in the show, the thing I remember the most is at the Restaurant at the End of the Universe where the animal that wants to be eaten.

In middle school I finally read the first book and in high school school I read everything available in the series at the time.  I also explored and enjoyed the world of Dirk Gently and his Holistic Detective Agency (my favourite part of those books being the sofa in the stairway).  By then I was sufficiently well-versed in the works to be able to claim to know the location of my towel.

In college there was a guy in the dorm that had the original radio show in cassette tape and he was kind enough to let me make a copy.  I’m typically not a fan of that sort of audio format–it’s much slower than reading and requires more effort than media that has associated visual components.  Nevertheless, I really enjoy the radio show and it is my preferred version of the story.  Over the years first the radio show (now in mp3 format rather than cassette) has continued to provide entertainment during road trips.

I enjoy the silliness associated with “The Guide” in all it’s many forms–it has been and continues to be a source of entertainment for me and my family.  If I had to choose a favourite media format, I would have to go with the radio show version.  While I suspect that more people have read the book, I feel it is definitely worth a listen.
